Structural Plywood

Ecoply^® Structural Square Edge plywood is structural-grade plywood. With a range of uses throughout the building industry, it is commonly selected for uses such as bracing, interior linings, membrane substrates, hoardings and DIY projects, where known structural characteristics are required. It is available in a wide range of surface appearance grades, sheet sizes, thicknesses and treatments.

Ecoply installation guidelines must be followed.

View Data Spreadsheets

Contact

Features & Benefits

Manufactured from sustainably grown Australian and New Zealand Plantation Radiata Pine.
Available in B, C and D surface appearance grades
Sheet thicknesses 7mm to 42mm
Sheet dimensions 2400/2700 x 1200mm
Available untreated, H2 gluetine treated and H3 LOSP treated
Low formaldehyde emission, Super E0 < 0.3mg/L as tested to AS/NZS 2098.11
Myrtleford mill EWPAA certified here.
Tokoroa mill FSC® certified (FSC-C012019) here.

Ecoply^® Structural Square Edge Range

Thickness (mm)	Length (mm)	Width (mm)	Grade CD	Grade DD	Sheets Per Pack	Coverage per Sheet (m2)	Mass Weight (kg/m2)
7	2400	1200	Y	Y	75	2.88	3.8
7	2700	1200	Y		75	3.24	3.8
9	2400	1200	Y	Y	60	2.88	4.9
9	2700	1200	Y		60	3.24	4.9
12	2400	1200	Y	Y	45	2.88	6.6
12	2700	1200	Y		45	3.24	6.6
12	2400	1200	Y	Y	45	2.88	6.6
15	2400	1200	Y	Y	35	2.88	8.2
15	2700	1200	Y		35	3.24	8.2
17	2400	1200	Y	Y	32	2.88	9.3
17	2700	1200	Y		32	3.24	9.3
17	2400	1200	Y	Y	32	2.88	9.2
17	2700	1200	Y		32	3.24	9.2
19	2400	1200	Y	Y	28	2.88	10.4
19	2700	1200	Y		28	3.24	10.4
21	2400	1200	Y	Y	25	2.88	11.5
21	2700	1200	Y		25	3.24	11.5
25	2400	1200	Y	Y	20	2.88	13.9
25	2700	1200	Y		20	3.24	13.9
32	2400	1200	Y	Y	15	2.88	17.6
42	2400	1200	Y		15	2.88	23.1

Compliance

Ecoply Structural Square Edge plywood is manufactured under a third-party audited quality control program and is certified by the Engineered Wood Products Association of Australasia (EWPAA) as compliant with AS/NZS 2269 for Structural Plywood.

*The information and media content on this page is sourced from CHH Plywood.
For more information, please visit their site: https://chhply.com.au/

Download Resources

Thank-you for your interest in our products. To download the additional resources please enter your details below.

"*" indicates required fields

Technical Note	Description
Ecoply H2 S Termite Treated Plywood	Chemwatch Material Safety Data Sheet Australia.	Download PDF
Ecoply SDS Untreated Plywood	Chemwatch Material Safety Data Sheet.	Download PDF
Ecoply SDS H3.1 LOSP Azole Treated Plywood	Chemwatch Material Safety Data Sheet Australia.	Download PDF
Plywood Class 2 and 3 Surface Finishes	Plywood Class 2 and 3 Surface Finishes.	Download PDF
Ecoply and Structural Plywood Packaging	Ecoply is regularly used to manufacture boxes, pallets and crates, including packaging for export.	Download PDF
